Electric pallet truck with integrated scale
F4 with Scale
- Load capacity
- 1,500 kg
- Lift height
- 105 mm
- Battery
- 24 V Li-ion
Overview
An electric pallet truck with integrated scale with a rated capacity of 1,500 kg, a lift height of 105 mm and a 24 V Li-ion battery.
Specifications
Specifications per EP Equipment. Contact us to confirm availability and configuration for Aruba.
- Load capacity
- 1,500 kg
- Lift height
- 105 mm
- Travel speed, laden/unladen
- 4 / 4.5 km/h
- Battery
- 24 V Li-ion
- Turning radius
- 1,380 mm
Show all specifications Hide specifications
Capacity and lifting
- Load centre distance
- 600 mm
- Load distance, centre of drive axle to fork
- 955 mm
- Lift speed, laden/unladen
- 0.017 / 0.023 m/s
- Lowering speed, laden/unladen
- 0.035 / 0.053 m/s
Performance
- Max. gradeability, laden/unladen
- 5 / 16 %
- Service brake
- Electromagnetic
Battery and drive
- Drive motor rating S2 60 min
- 0.75 kW
- Lift motor rating at S3 15%
- 0.5 kW
- Battery voltage
- 24 V
- Battery nominal capacity K5
- 20 Ah
- Battery type
- Li-ion
- Battery weight
- 5 kg
- Type of drive unit
- DC
Dimensions and weight
- Wheelbase
- 1,215 mm
- Service weight
- 155 kg
- Axle loading, laden front/rear
- 527/1,128 kg
- Axle loading, unladen front/rear
- 116/39 kg
- Tread width, rear
- 530/405 mm
- Height, lowered
- 82 mm
- Overall length
- 1,575 mm
- Length to face of forks
- 425 mm
- Overall width
- 695/590 mm
- Fork dimensions
- 60/155/1,150 mm
- Aisle width for pallets 1000×1200 crossways
- 2,190 mm
- Aisle width for pallets 800 × 1200 lengthways
- 2,055 mm
Wheels and tyres
- Tyres
- Polyurethane
- Tyre size, front
- 210 × 70mm
- Tyre size, rear
- Φ80 × 60 (Φ74 × 88)mm
- Additional wheels (castor wheels)
- Φ74 × 30 (Optional)mm
- Wheels, number front/rear (x=drive wheels)
- 1 × 2/4, (1 × 2/2)
General
- Drive
- Electric
- Operator type
- Pedestrian
- Steering design
- Mechanical
- Sound pressure level at the driver's seat
- 74 dB(A)
