Electric seated pallet truck
EPT20-SR2
- Load capacity
- 2,000 kg
- Lift height
- 120 mm
- Battery
- 24 V Li-ion
Overview
An electric seated pallet truck with a rated capacity of 2,000 kg, a lift height of 120 mm and a 24 V Li-ion battery.
Specifications
Specifications per EP Equipment. Contact us to confirm availability and configuration for Aruba.
- Load capacity
- 2,000 kg
- Lift height
- 120 mm
- Travel speed, laden/unladen
- 5.5/6 km/h
- Battery
- 24 V Li-ion
- Turning radius
- 1,774 mm
Show all specifications Hide specifications
Capacity and lifting
- Load centre distance
- 600 mm
- Load distance, centre of drive axle to fork
- 980 mm
- Lift speed, laden/unladen
- 0.045/0.064 m/s
- Lowering speed, laden/unladen
- 0.05/0.027 m/s
Performance
- Height drawbar in driving position min./max.
- 1,306 mm
- Max. gradeability, laden/unladen
- 8/16 %
- Service brake
- Electromagnetic
Battery and drive
- Drive motor rating S2 60 min
- 1.6 kW
- Lift motor rating at S3 15%
- 0.84 kW
- Battery voltage
- 24 V
- Battery nominal capacity K5
- 100 Ah
- Battery type
- Li-ion
- Battery weight
- 43 kg
- Type of drive unit
- AC
Dimensions and weight
- Wheelbase
- 1,572 mm
- Service weight
- 460 kg
- Axle loading, laden front/rear
- 820/1,640 kg
- Axle loading, unladen front/rear
- 340/120 kg
- Tread width, front
- 490 mm
- Tread width, rear
- 370/515 mm
- Height, lowered
- 85 mm
- Width of loading surface
- 800
- Overall length
- 1,908 mm
- Length to face of forks
- 760 mm
- Overall width
- 800 mm
- Fork dimensions
- 55 × 170 × 1,150 mm
- Ground clearance, centre of wheelbase
- 30 mm
- Aisle width for pallets 1000×1200 crossways
- 2,538 mm
- Aisle width for pallets 800 × 1200 lengthways
- 2,395 mm
Wheels and tyres
- Tyres
- Polyurethane
- Tyre size, front
- Ф230 × 75mm
- Tyre size, rear
- 2x Ф85 × 70mm
- Additional wheels (castor wheels)
- Φ102 × 62.5mm
- Wheels, number front/rear (x=drive wheels)
- 1x+1/4
General
- Drive
- Electric
- Operator type
- Seated
- Distance between fork-arms
- 540/685 mm
- Steering design
- Electronic
- Sound pressure level at the driver's seat
- <74 dB(A)
Bought in Aruba. Supported in Aruba.
With ProLift you deal with one local partner, from the first question to service years later.
-
Ready to work
New machines are delivered fully assembled, inspected and ready to work.
-
Maintenance and repairs
Preventive maintenance and repairs to keep your machine running.
-
Parts
Support and parts arranged directly for Aruba, to keep downtime short.
-
One point of contact
One dedicated partner from the first quote to final delivery and beyond.
Interested in the EPT20-SR2?
Talk to ProLift. We'll help you choose the right configuration for your operation.
