Internal combustion counterbalanced forklift
CPCD50T9-6 (Cummins QSB3.9)
- Load capacity
- 5,000 kg
- Lift heightUp to 7,000 mm with optional mast
- 3,000 mm
- Drive
- Diesel
Overview
An internal combustion counterbalanced forklift with a rated capacity of 5,000 kg, a lift height of 3,000 mm (up to 7,000 mm with optional mast) and a diesel engine.
Specifications
Specifications per EP Equipment. Contact us to confirm availability and configuration for Aruba.
- Load capacity
- 5,000 kg
- Lift height (standard mast)
- 3,000 mm
- Max. lift height
- 7,000 mm with optional mast
- Travel speed, laden/unladen
- 27/30 km/h
- Drive
- Diesel
- Turning radius
- 3,230 mm
Show all specifications Hide specifications
Capacity and lifting
- Load centre distance
- 600 mm
- Load distance, centre of drive axle to fork
- 603.5 mm
- Tilt of mast/fork carriage forward/backward
- 6/12 °
- Height, mast lowered
- 2,480 mm
- Free lift
- 160 mm
- Height, mast extended
- 4,470 mm
- Fork carriage ISO 2328, class/type A, B
- 4A
- Fork carriage width
- 1,845 mm
- Lift speed, laden/unladen
- 0.53/0.55 m/s
- Lowering speed, laden/unladen
- 0.48/0.42 m/s
- Fuel tank capacity
- 140L
Performance
- Max. drawbar pull, laden/unladen
- 75000/NAN
- Max. gradeability, laden/unladen
- 20/NA %
- Service brake
- Hydraulic - foot pedaltype
- Parking brake
- Mechanical, lever type
- Max. torque/Speed
- 480/1350Nm/rpm
Battery and drive
- Drive motor rating S2 60 min
- Cummins QSB3.9 kW
- Lift motor rating at S3 15%
- 93/2,200 kW
- Cylinder count/Displacement
- 4/3.9/L
Dimensions and weight
- Wheelbase
- 2,300 mm
- Service weight
- 8,380 kg
- Axle loading, laden front/rear
- 12,157/1,223 kg
- Axle loading, unladen front/rear
- 4,541/3,839 kg
- Tread width, front
- 1,470 mm
- Tread width, rear
- 1,718 mm
- Height of overhead guard (cabin)
- 2,480 mm
- Seat height relating to SIP/stand height
- 1,370 mm
- Coupling height
- 454 mm
- Overall length
- 4,720 mm
- Length to face of forks
- 3,500 mm
- Overall width
- 2,000 mm
- Fork dimensions
- 60/150/1,220 mm
- Ground clearance, laden, below mast
- 160 mm
- Ground clearance, centre of wheelbase
- 213 mm
- Aisle width for pallets 1000×1200 crossways
- 5,033.5 mm
- Aisle width for pallets 800 × 1200 lengthways
- 5,233.5 mm
Wheels and tyres
- Tyres
- Pneumatic
- Tyre size, front
- 8.25-15-14PRmm
- Tyre size, rear
- 8.25-15-14PRmm
- Wheels, number front/rear (x=drive wheels)
- 4X/2
General
- Drive
- Diesel
- Operator type
- Seated
- Steering design
- Hydraulic
- Transmission type
- Electro-hydraulic
- Gear position, front/rear
- 2/2
